Synthesizing Data for Healthcare Records¶

Highly sensitive data, such as patient health records, is challenging to analyze and share. Using SDV, you can train generative AI models on your sensitive datasets and then use them to generate synthetic data. The synthetic data mirrors the statistical patterns in your real data and even adhere to the same business logic, but synthetic data will not expose explicit information on specific individuals.

In this tutorial, we will generate synthetic data for healthcare records. We will focus on inspecting the data properties and making sure we configure the synthesizer properly to model the data.

import warnings

warnings.filterwarnings('ignore')

Understanding the Data¶

We'll be using a dataset called SyntheaMass, which is a multi-table, healthcare dataset containing tables on patients, payers, and more. We'll treat this dataset as our real, sensitive data, use it to train a model in the SDV, and finally use that model to generate synthetic data.

Here's a description of the tables in this dataset:

Table	Description
patients	Patient info, including key dates, identifiers, address, and race information
encounters	Patients' encounters with the healthcare system (outpatient care, ambulance care, etc), including dates, payer, and cost.
medications	Patients' medication history, including dates, payer, and cost.
careplans	Patients' treatment plans, including dates, and type.
immunizations	Patients' immunization records, including cost and type.
observations	Patients' recorded health metrics, including type and units.
imaging_studies	Imaging procedure records for patients, including procedure and modality codes.
devices	Issued medical devices to patients, including dates and types.
supplies	Information on health supplies patients receive or use, including dates and types.
allergies	Patients' allergy records, including dates, severity, and type.
procedures	Patients' medical procedures, including dates, codes, and reasons.
conditions	Patients' medical conditions, including dates and description.
payers	Payer info, including location, revenue, and amount covered.
payer_transitions	Info on patients and their insurance payer over time, including dates and ownership.
organizations	Info on healthcare organizations, like clinics and hospitals, including location, utilization, and revenue.
providers	Info on specific clinicians, including location and utilization.
claims	Info on all insurance claims on behalf of patients, including diagnoses, appointments, statuses, and billing dates.
claims_transactions	Info on all payments made to settle claims, including diagnoses, appointments, and payment details.

This datasets is available as a demo dataset in SDV. To load the datasets we can use the download_demo functionality and pass in synthea as the name of the dataset. The function will retrieve the dataset and its associated metadata.

Let's start by downloading the data then check that it contains 18 tables.

from sdv.datasets.demo import download_demo

real_data, metadata = download_demo(modality='multi_table', dataset_name='synthea')
real_data.keys()

dict_keys(['allergies', 'careplans', 'claims', 'claims_transactions', 'conditions', 'devices', 'encounters', 'imaging_studies', 'immunizations', 'medications', 'observations', 'organizations', 'patients', 'payer_transitions', 'payers', 'procedures', 'providers', 'supplies'])

Some of the columns in the data only contain null values and aren't useful for the SDV, so let's drop them.

null_columns_dict = {}

for name, df in real_data.items():
    null_columns = df.columns[df.isnull().all()]
    null_columns_dict[name] = null_columns.tolist()
    real_data[name].drop(columns=null_columns, inplace=True)

Updating the Metadata¶

The metadata is already provided to us, but in cases where we do not have it, we can use SDV's detection functionality to create an initial version of the metadata:

from sdv.metadata import Metadata

metadata = Metadata.detect_from_dataframes(real_data)

If we visualize the metadata in a diagram, the complexity of the data stands out to us immediately.

metadata.visualize(show_table_details=None, show_relationship_labels=False)

No description has been provided for this image

SDV automatically identified all of the key relationships between the tables in the data so no updates are needed here. Identifying the right sdtype automatically is much more challenging and an imperfect process, so we'll need to inspect the metadata and manually update the sdtypes if needed.

First, let's update the metadata for the organizations table. Majority of the fields in this table were assigned the unknown sdtype, which means that the SDV will have a hard time generating high quality synthetic values for these columns.

Some columns in organizations table with their correct sdtype:

Column	Correct SDType	Reason
NAME	categorical	This will ensure the same organization names are replicated in the synthetic data.
ADDRESS	address	SDV will know to generate realistic addresses
ZIP	postcode	SDV will know to generate realistic postal codes
LAT	latitude	SDV will know to generate realistic latitude values
LON	longitude	SDV will know to generate realistic longitude values
PHONE	phone_number	SDV will know to generate realistic phone numbers
REVENUE	numerical	SDV will estimate the distribution in the real data and mirror it in the synthetic data.

We can run the following code snippet to update our metadata to reflect these changes:

metadata.update_columns_metadata(
    table_name='organizations',
    column_metadata={
        'NAME': { 'sdtype': 'categorical'},
        'ADDRESS': { 'sdtype': 'address' },
        'ZIP': { 'sdtype': 'postcode'},
        'LAT': { 'sdtype': 'latitude'},
        'LON': { 'sdtype': 'longitude'},
        'PHONE': { 'sdtype': 'phone_number'},
        'REVENUE': { 'sdtype': 'numerical'},
    }
)

Next, let's update the conditions table.

Column	Correct SDType	Reason
START	datetime	Let’s specify the datetime format for SDV to use during synthesis.
STOP	datetime	Let’s specify the datetime format for SDV to use during synthesis.
CODE	categorical	The values in this column are fixed and we want SDV to replicate them in the synthetic data.

We can run the following code snippet to update our metadata to reflect these changes:

metadata.update_columns_metadata(
    table_name='conditions',
    column_metadata={
        'START': {'sdtype': 'datetime', 'datetime_format': '%Y-%m-%d' },
        'STOP': {'sdtype': 'datetime', 'datetime_format': '%Y-%m-%d'},
        'CODE': {'sdtype': 'categorical'}
    }
)

We also need to update the metadata to remove the columns that contain no information

for name, columns in null_columns_dict.items():
    for column_name in columns:
        metadata.remove_column(column_name=column_name, table_name=name)

After you've finished modifying the metadata, let's validate the metadata. The following lines of code will validate that our metadata follows the spec that SDV expects and then will validate that the metadata accurately describes the dataset. If both validate successfully, we will see no output.

metadata.validate()
metadata.validate_data(real_data)

Adding Constraints and Assigning Transformers¶

Real world data often has subtle and specific business rules that must be adhered to in synthetic data. To define those rules for the SDV to incorporate during sampling, we need to define these as Constraints.

Identifying potential constraints is a bit of an art and we'll walk you through how we identified some of the constraints for this tutorial before showing the code you need to run.

If we look more closely at the patients table, we can surmise a link between the PREFIX and GENDER columns.

real_data['patients'].head()

	Id	BIRTHDATE	DEATHDATE	SSN	DRIVERS	PASSPORT	PREFIX	FIRST	LAST	SUFFIX	...	BIRTHPLACE	ADDRESS	CITY	STATE	COUNTY	ZIP	LAT	LON	HEALTHCARE_EXPENSES	HEALTHCARE_COVERAGE
0	b9c610cd-28a6-4636-ccb6-c7a0d2a4cb85	2019-02-17	NaN	999-65-3251	NaN	NaN	NaN	Damon455	Langosh790	NaN	...	Middleborough Massachusetts US	620 Lynch Tunnel Apt 0	Springfield	Massachusetts	Hampden County	1104.0	42.080389	-72.480431	9039.1645	7964.1255
1	c1f1fcaa-82fd-d5b7-3544-c8f9708b06a8	2005-07-04	NaN	999-49-3323	S99941126	NaN	NaN	Thi53	Wunsch504	NaN	...	Danvers Massachusetts US	972 Tillman Branch Suite 48	Bellingham	Massachusetts	Norfolk County	NaN	42.035213	-71.482519	402723.4150	14064.1350
2	339144f8-50e1-633e-a013-f361391c4cff	1998-05-11	NaN	999-10-8743	S99996708	X75063318X	Mr.	Chi716	Greenfelder433	NaN	...	Athens Athens Prefecture GR	1060 Bernhard Crossroad Suite 15	Boston	Massachusetts	Suffolk County	2131.0	42.292557	-71.061160	571935.8725	787.5375
3	d488232e-bf14-4bed-08c0-a82f34b6a197	2003-01-28	NaN	999-56-6057	S99929424	NaN	Ms.	Phillis443	Walter473	NaN	...	Boston Massachusetts US	677 Ritchie Terrace	Hingham	Massachusetts	Plymouth County	2043.0	42.200491	-70.916076	582557.8030	104782.2070
4	217f95a3-4e10-bd5d-fb67-0cfb5e8ba075	1993-12-23	NaN	999-91-4320	S99991143	X44132498X	Mr.	Jerrold404	Herzog843	NaN	...	Boston Massachusetts US	276 Bernier Branch	Revere	Massachusetts	Suffolk County	NaN	42.381875	-70.999286	475826.8550	18067.0950

5 rows × 25 columns

Both of them indicate information either directly or indirectly about a patient's gender. If we cross-tabulate both of these columns, we can tell that these columns are connected.

real_data['patients'][['PREFIX', 'GENDER']].value_counts(dropna=False)

PREFIX  GENDER
Mr.     M         431
Mrs.    F         331
Ms.     F         156
NaN     F         129
        M         116
Name: count, dtype: int64

As expected, male patients (M) only have one prefix (Mr.) while female patients have a few (Mrs. or Ms.). From this cross tabulation, we can clearly deduce that these are the only valid combinations of values in these two columns. To guarantee that our synthetic data won't have invalid pairs of values (e.g. a PREFIX of "Mr." with a GENDER of "F"), we need to define this business rule as an instance of the FixedCombinations constraint. To define it, we just craft a dictionary object that follows the structure in the documentation that contains the name of the constraint, relevant table name, and the constraint parameters (in this case the two or more columns involved).

from sdv.cag import FixedCombinations

patients_constraint_1 = FixedCombinations(
    table_name='patients',
    column_names=['PREFIX', 'GENDER']
)

A similar dependence exists in the conditions table, between the CODE and DESCRIPTION columns.

real_data['conditions'][['CODE', 'DESCRIPTION']].value_counts(dropna=False)

CODE            DESCRIPTION
160903007       Full-time employment (finding)                                                    13805
73595000        Stress (finding)                                                                   5137
160904001       Part-time employment (finding)                                                     2426
422650009       Social isolation (finding)                                                         1243
444814009       Viral sinusitis (disorder)                                                         1233
                                                                                                  ...
425048006       Non-small cell carcinoma of lung  TNM stage 2 (disorder)                              1
427089005       Male Infertility                                                                      1
431856006       Chronic kidney disease stage 2 (disorder)                                             1
1501000119109   Proliferative diabetic retinopathy due to type II diabetes mellitus (disorder)        1
90781000119102  Microalbuminuria due to type 2 diabetes mellitus (disorder)                           1
Name: count, Length: 204, dtype: int64

If we inspect all 204 pairs of values in this cross-tabulation, we'll notice that a given code value always maps to the same description value. A code never pairs with two description values. This lines up with our own intuition and understanding of this domain; medical codes (as numbers) are often used to represent another concept.

Let's define this constraint as well.

conditions_constraint_1 = FixedCombinations(
    table_name='conditions',
    column_names=['CODE', 'DESCRIPTION']
)

FixedCombinations constraints can span multiple columns and the same table can have multiple, non-overlapping constraints that have to be defined. Let's highlight examples from the imaging_studies table, starting with the following 4 columns:

real_data['imaging_studies'][[
    'BODYSITE_CODE',
    'BODYSITE_DESCRIPTION',
    'MODALITY_CODE',
    'MODALITY_DESCRIPTION',
]].value_counts(dropna=False)

BODYSITE_CODE  BODYSITE_DESCRIPTION                          MODALITY_CODE  MODALITY_DESCRIPTION
51185008       Thoracic structure (body structure)           CT             Computed Tomography     151094
80891009       Heart structure (body structure)              US             Ultrasound                 221
51185008       Thoracic structure (body structure)           CR             Computed Radiography       104
8205005        Wrist                                         DX             Digital Radiography         51
40983000       Arm                                           DX             Digital Radiography         43
344001         Ankle                                         DX             Digital Radiography         41
51299004       Clavicle                                      DX             Digital Radiography         36
72696002       Knee                                          DX             Digital Radiography         18
51185008       Chest                                         DX             Digital Radiography         13
12921003       Pelvis                                        DX             Digital Radiography         12
50519007       Structure of right upper quadrant of abdomen  US             Ultrasound                   4
Name: count, dtype: int64

This table has ~151,000 rows but these columns only contain these 11 specific combinations of values. Another example from the same table is the SOP_CODE and SOP_DESCRIPTION columns.

real_data['imaging_studies'][['SOP_CODE', 'SOP_DESCRIPTION']].value_counts(dropna=False)

SOP_CODE                     SOP_DESCRIPTION
1.2.840.10008.5.1.4.1.1.2    CT Image Storage                                  151094
1.2.840.10008.5.1.4.1.1.3.1  Ultrasound Multiframe Image Storage                  221
1.2.840.10008.5.1.4.1.1.1.1  Digital X-Ray Image Storage                          214
                             Digital X-Ray Image Storage – for Presentation       104
1.2.840.10008.5.1.4.1.1.6.1  Ultrasound Image Storage                               4
Name: count, dtype: int64

We can define these constraints the same way we did earlier:

imaging_studies_constraint_1 = FixedCombinations(
    table_name='imaging_studies',
    column_names=[
        'BODYSITE_CODE',
        'BODYSITE_DESCRIPTION',
        'MODALITY_CODE',
        'MODALITY_DESCRIPTION'
    ]
)

imaging_studies_constraint_2 = FixedCombinations(
    table_name='imaging_studies',
    column_names=['SOP_CODE', 'SOP_DESCRIPTION']
)

The remaining constraints in this dataset are all FixedCombinations constraints and follow the same general pattern. There's at least 10 more constraints we need to define.

## observations table
observations_constraint_1 = FixedCombinations(
    table_name='observations', column_names=['CODE', 'DESCRIPTION']
)
observations_constraint_2 = FixedCombinations(
    table_name='observations', column_names=['UNITS', 'TYPE']
)

## immunizations table
immunizations_constraint_1 = FixedCombinations(
    table_name='immunizations', column_names=['CODE', 'DESCRIPTION']
)

## claims table
claims_constraint_1 = FixedCombinations(
    table_name='claims', column_names=['HEALTHCARECLAIMTYPEID1', 'HEALTHCARECLAIMTYPEID2']
)

## allergies table
allergies_constraint_1 = FixedCombinations(
    table_name='allergies', column_names=['CODE', 'DESCRIPTION']
)
allergies_constraint_2 = FixedCombinations(
    table_name='allergies', column_names=['REACTION1', 'DESCRIPTION1']
)
allergies_constraint_3 = FixedCombinations(
    table_name='allergies', column_names=['REACTION2', 'DESCRIPTION2']
)

## careplans table
careplans_constraint_1 = FixedCombinations(
    table_name='careplans', column_names=['CODE', 'DESCRIPTION']
)
careplans_constraint_2 = FixedCombinations(
    table_name='careplans', column_names=['REASONCODE', 'REASONDESCRIPTION']
)

## imaging studies table
imaging_studies_constraint_3 = FixedCombinations(
    table_name='imaging_studies', column_names=['INSTANCE_UID', 'PROCEDURE_CODE']
)

## device table
devices_constraint_1 = FixedCombinations(
    table_name='devices', column_names=['CODE', 'DESCRIPTION']
)

## encounters table
encounters_constraint_1 = FixedCombinations(
    table_name='encounters', column_names=['CODE', 'DESCRIPTION']
)
encounters_constraint_2 = FixedCombinations(
    table_name='encounters', column_names=['REASONCODE', 'REASONDESCRIPTION']
)

## supplies table
supplies_constraint_1 = FixedCombinations(
    table_name='supplies', column_names=['CODE', 'DESCRIPTION']
)

## claims transactions table
claims_transactions_constraint_1 = FixedCombinations(
    table_name='claims_transactions', column_names=['TYPE', 'METHOD']
)

To incorporate all of these constraints when SDV is generating synthetic data, we need to instantiate a synthesizer object and then attach these constraints to that object.

from sdv.multi_table import HSASynthesizer

hsa_synthesizer = HSASynthesizer(metadata)

hsa_synthesizer.add_constraints(constraints=[
    patients_constraint_1, conditions_constraint_1,
    observations_constraint_1, observations_constraint_2,
    immunizations_constraint_1, claims_constraint_1,
    allergies_constraint_1, allergies_constraint_2,
    allergies_constraint_3, careplans_constraint_1,
    careplans_constraint_2, imaging_studies_constraint_1,
    imaging_studies_constraint_2, imaging_studies_constraint_3,
    devices_constraint_1, encounters_constraint_1,
    encounters_constraint_2, supplies_constraint_1,
    claims_transactions_constraint_1
])

Our dataset contains two columns that represent phone numbers. To replace them with a random phone number in the synthetic data, let's update the transformers for these columns.

First, we need to start by asking SDV to detect and establish baseline transformers using the auto_assign_transformers() method.

hsa_synthesizer.auto_assign_transformers(real_data)

Next, let's use the update_transformers() method to update the assigned transformers for our 2 phone number columns to AnonymizedFaker.

from rdt.transformers.pii import AnonymizedFaker

hsa_synthesizer.update_transformers(
    table_name='organizations',
    column_name_to_transformer= {'PHONE':
        AnonymizedFaker(provider_name="phone_number",
        function_name="phone_number")
})

hsa_synthesizer.update_transformers(
    table_name='payers',
    column_name_to_transformer={'PHONE':
        AnonymizedFaker(provider_name="phone_number",
        function_name="phone_number")
})

Generating Synthetic Data and Evaluating Quality¶

Let's fit the synthesizer and then sample to match the same approximate ratio of rows as our original data.

hsa_synthesizer.fit(real_data)
synthetic_data = hsa_synthesizer.sample(1.0)

Next, let's generate a quality report to understand how well the synthetic data mirrors the patterns in our real data.

from sdv.evaluation.multi_table import evaluate_quality

quality_report = evaluate_quality(
    real_data=real_data,
    synthetic_data=synthetic_data,
    metadata=metadata,
    verbose=False
)

First, let's unpack how well the SDV mirrored the distribution shapes from the real data, starting with the patients table.

fig = quality_report.get_visualization(
    property_name='Column Shapes',
    table_name='patients')

fig.update_layout(width=1200)
fig.show()

An overall average score of 0.85 is considered very good. Let's specifically compare the distributions of the HEALTHCARE_EXPENSES from the patients table.

from sdv.evaluation.multi_table import get_column_plot

fig = get_column_plot(
    real_data=real_data,
    synthetic_data=synthetic_data,
    metadata=metadata,
    table_name='patients',
    column_name='HEALTHCARE_EXPENSES',
    plot_type='distplot'
)

fig.update_layout(width=1200)
fig.show()

We can observe first hand how the high score from the column shapes bar plot for this table reflects the distribution similarity for this specific column. Next, let's look at the allergies table.

fig = quality_report.get_visualization(
    property_name='Column Shapes',
    table_name='allergies')

fig.update_layout(width=1200)
fig.show()

The synthetic data in the allergies table also scored very high (0.95). The blue bars represent the similarity scores for the categorical columns in the real data, which were especially well recreated in the synthetic data.

Next Steps¶

We generated healthcare records using SDV and evaluated its quality. To evaluate how well your synthetic data preserves privacy of sensitive information, we can use the CategoricalCAP metric.
